起源の場所:
ホンシュイ、河北、中国
ブランド名:
Heng Yuan
証明:
ISO9000
モデル番号:
12-3/4インチ 10-3/4インチ 8-5/8インチ 6-5/8インチ
私達に連絡しなさい
High-performance wire wrapped screen designed for water well sand control applications, available in various materials and configurations to meet specific filtration requirements.
| Size (inch) | OD (mm) | Slot (mm) | Length (m) | Tensile Strength | Collapse Strength | Wrap Wire (mm) | Support Rod (mm) |
|---|---|---|---|---|---|---|---|
| 3-1/2 | 88.9 | 1.0 | 2.9 | ＞22 | 10.2 | 2.0×3.5 | ø3.8×22 |
| 4-1/2 | 114.3 | 1.0 | 2.9 | ＞28 | 11.5 | 2.0×3.5 | ø3.8×22 |
| 6-5/8 | 168.3 | 0.75 | 5.8 | ＞40 | 12.8 | 2.0×3.5 | ø3.8×32 |
| 6-5/8 | 168.3 | 1.0 | 5.8 | ＞33 | 12.8 | 2.2×3.5 | ø3.8×32 |
| 8-5/8 | 219.1 | 1.0 | 5.8 | ＞50 | 38.2 | 3.0×4.6 | ø4.0×48 |
| 10-3/4 | 273.1 | 1.0 | 5.8 | ＞60 | 39.5 | 3.0×4.6 | ø4.8×55 |
